The European Type Hose Clamp is widly used on the joints of oil, gas, liquid and rubber hose of the automobile, ship, tractor, sprinkler, gasoline engine, diesel engine and other mechanical equipment, and also in the construction, fire and other fields of industry.
General purpose automotive and industrial clamps
High strength 4-piece quadra-lock construction
Exceeds all SAE requirements
Use for all standard clamp applications
European Type Hose Clamp
The European Type Hose Clamp is widly used on the joints of oil, gas, liquid and rubber hose of the automobile, ship, tractor, sprinkler, gasoline engine, diesel engine and other mechanical equipment, and also in the construction, fire and other fields of industry.
General purpose automotive and industrial clamps
High strength 4-piece quadra-lock construction
Exceeds all SAE requirements
Use for all standard clamp applications
| European Type Hose Clamp -- 12.7mm | |||||||
Material:
| |||||||
| Size | Bandwidth * Thickness (mm) | Pcs/Bag | Pcs/Ctn (cm) | Ctn Size (cm) | G.W./ Ctn (kg) | Torque (N.m) | |
| mm | inch | ||||||
| 10-16 | 5/8" | 12.7*0.6 | 100 | 1000 | 38*27*24 | 14.80 | ≥6.8 |
| 13-19 | 3/4" | 12.7*0.6 | 100 | 1000 | 38*27*29 | 16.40 | ≥6.8 |
| 16-25 | 1" | 12.7*0.6 | 100 | 1000 | 38*27*29 | 18.00 | ≥6.8 |
| 22-32 | 1 1/4" | 12.7*0.6 | 50 | 1000 | 40*37*28 | 19.90 | ≥6.8 |
| 25-38 | 1 1/2" | 12.7*0.6 | 50 | 1000 | 40*37*30 | 20.90 | ≥6.8 |
| 32-44 | 1 3/4" | 12.7*0.6 | 50 | 500 | 38*27*21 | 11.30 | ≥6.8 |
| 35-51 | 2" | 12.7*0.6 | 50 | 500 | 38*27*24 | 11.70 | ≥6.8 |
| 38-57 | 2 1/4" | 12.7*0.6 | 25 | 500 | 38*27*29 | 12.20 | ≥6.8 |
| 44-64 | 2 1/2" | 12.7*0.6 | 25 | 500 | 38*27*34 | 12.70 | ≥6.8 |
| 51-70 | 2 3/4" | 12.7*0.6 | 25 | 500 | 40*37*28 | 13.50 | ≥6.8 |
| 64-76 | 3" | 12.7*0.6 | 25 | 500 | 40*37*30 | 14.90 | ≥6.8 |
| 70-89 | 3 1/2" | 12.7*0.6 | 25 | 250 | 38*27*15 | 7.50 | ≥6.8 |
| 76-92 | 3 3/4" | 12.7*0.6 | 25 | 250 | 38*27*17 | 8.30 | ≥6.8 |
| 80-100 | 4" | 12.7*0.6 | 10 | 250 | 38*27*19 | 8.30 | ≥6.8 |
| 90-110 | 4 1/4" | 12.7*0.6 | 10 | 250 | 38*27*21 | 9.00 | ≥6.8 |
| 100-120 | 4 3/4" | 12.7*0.6 | 10 | 250 | 38*27*24 | 9.30 | ≥6.8 |
| 110-130 | 5" | 12.7*0.6 | 10 | 250 | 38*27*29 | 9.70 | ≥6.8 |
| 120-140 | 5 1/4" | 12.7*0.6 | 10 | 250 | 38*27*34 | 10.10 | ≥6.8 |
| 130-150 | 5 1/2" | 12.7*0.6 | 10 | 250 | 40*37*28 | 10.30 | ≥6.8 |
| 140-160 | 6" | 12.7*0.6 | 10 | 250 | 40*37*30 | 10.80 | ≥6.8 |
| 150-170 | 6 1/2" | 12.7*0.6 | 10 | 200 | 38*27*34 | 9.30 | ≥6.8 |
| 160-180 | 7" | 12.7*0.6 | 10 | 200 | 40*37*28 | 9.80 | ≥6.8 |
| European Type Hose Clamp -- 14.2mm | |||||||
Material:
| |||||||
| Size | Bandwidth * Thickness (mm) | Pcs/ Bag | Pcs / Ctn | G.W./ Ctn (kg) | Ctn Size (cm) | Torque (N. m) | |
| mm | inch | ||||||
| 16-25 | 1" | 14.2*0.6 | 50 | 500 | 11.20 | 38*27*15 | ≥8 |
| 18-32 | 1-1/4" | 14.2*0.6 | 50 | 500 | 11.55 | 38*27*17 | ≥8 |
| 21-38 | 1-1/2" | 14.2*0.6 | 50 | 500 | 12.15 | 38*27*21 | ≥8 |
| 21-44 | 1-3/4" | 14.2*0.6 | 50 | 500 | 12.95 | 38*27*24 | ≥8 |
| 27-51 | 2" | 14.2*0.6 | 50 | 500 | 14.05 | 38*27*24 | ≥8 |
| 33-57 | 2-1/4" | 14.2*0.6 | 50 | 500 | 14.65 | 38*27*29 | ≥8 |
| 40-63 | 2-1/2" | 14.2*0.6 | 50 | 500 | 15.20 | 38*27*31 | ≥8 |
| 46-70 | 2-3/4" | 14.2*0.6 | 50 | 500 | 16.05 | 39*31*25 | ≥8 |
| 52-76 | 3" | 14.2*0.6 | 25 | 250 | 8.98 | 38*27*21 | ≥8 |
| 59-82 | 3-1/4" | 14.2*0.6 | 25 | 250 | 9.38 | 38*27*21 | ≥8 |
| 65-89 | 3-1/2" | 14.2*0.6 | 25 | 250 | 9.78 | 38*27*24 | ≥8 |
| 72-95 | 3-3/4" | 14.2*0.6 | 25 | 250 | 10.18 | 38*27*24 | ≥8 |
| 78-101 | 4" | 14.2*0.6 | 25 | 200 | 8.78 | 38*27*29 | ≥8 |
| 84-108 | 4-1/4" | 14.2*0.6 | 25 | 200 | 9.24 | 38*27*29 | ≥8 |
| 91-114 | 4-1/2" | 14.2*0.6 | 25 | 200 | 9.58 | 40*37*35 | ≥8 |
| 105-127 | 5" | 14.2*0.6 | 25 | 200 | 10.10 | 40*37*35 | ≥8 |
| 117-140 | 5-1/2" | 14.2*0.6 | 25 | 200 | 10.68 | 48*34*37 | ≥8 |
| 130-153 | 6" | 14.2*0.6 | 25 | 200 | 11.38 | 48*34*37 | ≥8 |
| 142-165 | 6-1/2" | 14.2*0.6 | 25 | 200 | 11.86 | 56*37*38 | ≥8 |
| 155-178 | 7" | 14.2*0.6 | 25 | 200 | 12.56 | 56*37*38 | ≥8 |
