This type pipe clamp is used to mount, brace, support, and connect lightweight structural loads in building construction, including pipes, electrical, data wire, mechanical systems such as ventilation, air conditioning.
Usage:
For fastening: Pipe lines, such as heating, sanitary and waste water pipes, to walls, ceilings and floors.
Used for mounting of pipes to the walls ( vertical / horizontal ) , ceilings and floors.
For Suspending Stationary Non-Insulated Copper Tubing Lines.
Pipe Clamp with Rubber
This type pipe clamp is used to mount, brace, support, and connect lightweight structural loads in building construction, including pipes, electrical, data wire, mechanical systems such as ventilation, air conditioning.
Usage:
1. For fastening: Pipe lines, such as heating, sanitary and waste water pipes, to walls, ceilings and floors.
2. Used for mounting of pipes to the walls ( vertical / horizontal ) , ceilings and floors.
3. For Suspending Stationary Non-Insulated Copper Tubing Lines.
| Pipe Clamp with Rubber | |||||||
Material: W1 series -- all the parts are carbon steel W4 series -- all the parts are SS200 or 300 W5 series -- all the parts are SS316 | |||||||
| Size | Bandwidth * Thickness (mm) | Welded Nut | Side Screw | Pcs / Ctn | Ctn Size (cm) | G. W. / Ctn (kg) | |
| mm | inch | ||||||
| 15-19 | 3/8" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 200 | 38*27*15 | 13.28 |
| 20-25 | 1/2" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 200 | 38*27*17 | 14.81 |
| 26-30 | 3/4" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 200 | 38*27*19 | 16.09 |
| 32-36 | 1" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 200 | 38*27*24 | 17.63 |
| 38-43 | 1-1/4" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*13 | 9.71 |
| 47-51 | 1-1/2" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*15 | 10.73 |
| 53-58 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*17 | 11.62 | |
| 60-64 | 2" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*19 | 12.39 |
| 68-72 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*21 | 13.41 | |
| 75-80 | 2-1/2" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*24 | 14.44 |
| 71-86 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 38*27*34 | 15.20 | |
| 87-92 | 3" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 100 | 40*37*28 | 15.97 |
| 99-105 | 3-1/2" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*24 | 8.82 |
| 107-112 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*24 | 9.26 | |
| 113-118 | 4" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*24 | 9.65 |
| 125-130 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*29 | 10.41 | |
| 132-137 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*34 | 10.86 | |
| 138-142 | 5" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 38*27*34 | 11.18 |
| 148-152 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 40*37*29 | 11.82 | |
| 159-166 | 6" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 50 | 40*37*30 | 12.71 |
| 200-212 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 25 | 40*37*27 | 7.83 | |
| 215-220 | 8" | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 25 | 40*37*27 | 8.08 |
| 248-252 | 20*1.2/1.5/2.0 | M8+M10 | M6*20 | 25 | 40*37*30 | 9.10 | |
