Trico Form Aligner Turnbuckles allow for 6 inches of adjustment. The Turnbuckle is attached with nails or screws to lumber. The end of the turnbuckle contains a slot to accommodate a steel nail stake. It is used for Steel Ply Forming System supporting. Related accessories include x flat tie, wedge bolt and Clamp.
| Steel Plywood Forming System Accessories | |||
| Commodity | Type | Specification | Usage |
Turnbuckle Form Aligner
| Flat Plate | 3528g, Painted | Turnbuckles allow for 6 inches of adjustment. The Turnbuckle is attached with nails or screws to lumber. |
| Bent Plate | 3628g, Painted | ||
Attachment Plate | Painted | ||
X Flat Tie
| Standard Flat Tie | 4-48" Other Size Available Ultimate 6000lbs | X Flat Tie is used to lock steel panel and fillers during wall concrete |
Heavy Duty Flat Tie | 4-48" Other Size Available Ultimate 7000lbs | ||
Steel Ply Panels &Fillers
| Euro Form Steel Panel | Height: 2"-10" Width: 4"-24" Inner Corner and Outer Corner Available | Rugged steel frames are robotically welded for consistent strength and fit across all panels, fillers and corners. Exclusive DuraCoat powder coating helps keep the frame rust-free under the harshest conditions. |
Steel Ply Forming System is very popular for wall concrete construction.
Conveniently located handles make set up, stripping, and handling easier. With proper care, contractors can expect that forms will be able to be reused up to 200 times before plywood needs to be replaced. Compatible with all other industry-standard modular handset systems.All sizes of heavy-duty loop ties, x-flat ties, wedge bolts, and accessories to offer the complete system.
Packaging
Concrete Construction Steel Ply Forming System
